• Paint, solid
• Bumper, front, chrome, with Gray lower
• Bumper, rear, chrome step, includes pad
• Air dam, Gray
• Moldings, bodyside (Moldings are Black.)
• Grille, Gray surround, with chrome accent bar
• Headlamps, dual halogen composite, includes flash-to-pass feature and automatic lamp control
• Daytime running lamps, includes automatic exterior lamp control
• Lamps, dual cargo area lamps
• Mirrors, outside rearview, foldaway, manual, Black, adjustable
• Glass, Solar-Ray light tinted, all windows
• Windows, rear quarter swing-out (Standard with Extended Cab Models only)
• Wipers, intermittent, front, wet-arm with pulse washers

• Seat trim, vinyl
• Seats, front 40/20/40 split-bench, 3-passenger, driver and passenger manual reclining with outboard head restraints
• Seats, rear bench, full width, folding, 3-passenger (includes child seat top tether anchor) (Requires Extended or Crew Cab Models.)
• Floor covering, rubberized vinyl, Black
• Steering wheel, includes theft-deterrent locking feature
• Theft-deterrent system, PASSlock II
• Driver Information Center, monitors numerous systems depending on vehicle equipment
• Warning tones, headlamp on, key-in-ignition, driver and passenger buckle up reminder, turn signal on
• Cruise control, electronic with set and resume speed, includes telltale in instrument panel cluster
• Air conditioning, dual-zone, manual, individual climate settings for driver and right front passenger
• Sound system, ETR AM/FM stereo with CD player, includes seek-and-scan, digital clock, auto-tone control, speed-compensated volume, and Radio Data System (RDS)
• Sound system feature, 4-speakers
• Cupholders, front (Also includes rear cupholders on Extended and Crew Cab Models)
• Cigarette lighter, on instrument panel
• Power outlets, auxiliary, covered, 2 dash-mounted, 12-volt
• Mirror, inside rearview, manual day/night
• Visors, padded, Shale-colored, driver and passenger side with cloth trim, extenders, pocket on driver side and vanity mirror on passenger side
• Assist handle, front passenger (Also includes outboard rear assist handle on Extended or Crew Cab Models.)
• Lighting, dome lamp, reading, backlit instrument panel switches and door handle-activated illuminated entry
• Coat hook, driver side (Also includes passenger side coat hook on Extended and Crew Cab Models.)

• Brakes, 4-wheel antilock, front hydraulic disc and rear drum
• Air bags, frontal, driver and right front passenger, includes Passenger Sensing System (Always use safety belts and proper child restraints, even with air bags. Children are safer when properly secured in a rear seat. See the Owners Manual for more safety information)
• Daytime running lamps, includes automatic exterior lamp control

ENGINE, VORTEC 4300 V6 MFI ($0)

• (195 HP [145.4 kW] @ 4600 rpm
• 260 lb.-ft. [351.0 N-m] @ 2800 rpm) (STD)

• 3.23 Axle Ratio
• Front 40/20/40 Split-Bench Seat
• Custom Cloth Seat Trim
• Electronic Cruise Control w/Set & Resume Speed
• ETR AM/FM Stereo w/CD Player/Seek & Scan
• Rear Chrome Step Bumper w/Pad
• Solar-Ray Deep Tinted Glass
• Stainless Steel Black Coated Tubular Assist Steps
• Solid Smooth Ride Suspension Package
• Front beverage holders
• Variably intermittent wipers
• Tilt steering wheel
• Rear step bumper
• Power steering
• Passenger vanity mirror
• Passenger door bin
• Occupant sensing airbag
• Fully automatic headlights
• Front wheel independent suspension
• Front dual zone A/C
• Front anti-roll bar
• Dual front impact airbags
• Driver door bin
• Bumpers: chrome
• AM/FM radio
• ABS brakes
• Voltmeter
• Tachometer
• Air Conditioning

• Mileage
• EPA Fuel Economy Est - City (MPG): 16
• EPA Fuel Economy Est - Hwy (MPG): 21
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 600
• Maximum Alternator Capacity (amps): 145
• Cooling System
• Total Cooling System Capacity (qts): 16.4
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3600
• Gross Axle Wt Rating - Rear (lbs): 3686
• Curb Weight - Front (lbs): 2649
• Curb Weight - Rear (lbs): 1841
• Gross Vehicle Weight Rating Cap (lbs): 6200
• Gross Combined Wt Rating (lbs): 9500
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 600
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 5100
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 765
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): N/A
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): N/A
• Suspension
• Suspension Type - Front: Coil Spring
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Spring Capacity - Front (lbs): 3739
• Spring Capacity - Rear (lbs): 3686
• Axle Type - Front: Independent
• Axle Type - Rear: Semi-Floating
• Axle Capacity - Front (lbs): 3600
• Axle Capacity - Rear (lbs): 3750
• Axle Ratio (:1) - Rear: 3.23
• Shock Absorber Diameter - Front (mm): 35
• Shock Absorber Diameter - Rear (mm): 35
• Stabilizer Bar Diameter - Front (in): 1.42
• Brakes
• Brake Type: Hydraulic
• Brake ABS System: Four-Wheel
• Disc - Front (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.0 x 1.1
• Drum - Rear (Yes or ): Yes
• Rear Drum Diam x Width (in): 11.6 x 2.4
• Tires
• Front Tire Order Code: QPR
• Rear Tire Order Code: QPR
• Spare Tire Order Code: QPR
• Front Tire Size: P245/70R17
• Rear Tire Size: P245/70R17
• Spare Tire Size: P245/70R17
• Front Tire Capacity (lbs): - TBD -
• Rear Tire Capacity (lbs): - TBD -
• Spare Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 17 x 7.5
• Rear Wheel Size (in): 17 x 7.5
• Spare Wheel Size (in): 17 x 7.5
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr Recirculating Ball
• Steering Ratio (:1), On Center: 14.2
• Steering Ratio (:1), At Lock: 14.2
• Turning Diameter - Curb to Curb (ft): 46.6
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 26
• Fuel Tank Location: LH
• Exterior Dimensions
• Wheelbase (in): 143.5
• Length, Overall w/o rear bumper (in): 230.2
• Width, Max w/o mirrors (in): 78.5
• Height, Overall (in): 71.2
• Overhang, Front (in): 36.9
• Overhang, Rear w/o bumper (in): 47.3
• Front Bumper to Back of Cab (in): 138.5
• Cab to Axle (in): 41.9
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): 31.6
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): 42.0
• Ground Clearance, Front (in): 8.0
• Ground Clearance, Rear (in): 8.3
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 78.7
• Cargo Box Width @ Top, Rear (in): 63.8
• Cargo Box Width @ Floor (in): 64.8
• Cargo Box Width @ Wheelhousings (in): 50.0
• Cargo Box (Area) Height (in): 19.5
• Tailgate Width (in): 63.8
• Cargo Volume (ft³): 59.0
• Interior Dimensions
• Passenger Capacity: 6
• Front Head Room (in): 41.0
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 65.2
• Front Hip Room (in): 61.4
• Second Head Room (in): 38.4
• Second Leg Room (in): 33.7
• Second Shoulder Room (in): 66.3
• Second Hip Room (in): 61.4
• Summary
• Vehicle Name: Chevrolet Silverado 1500
• Body Style: Ext Cab 6.5' Fleetside
• Body Code: E63
